M-57 "Smoke Ring Nebula"
    Constellation:  Lyra

    Size:  86" x  63"

    Magnitude: 9.7

    Mag Central Star: 15.2

    RA:  18h 53m 35.1s

    Dec: 33m 01m 45s


Scope:   Nikon 28 mm Lens
Kodak Gold 200
Focal Ratio: f3.5
Exposure:  15 min

Click Here for a Larger Image



Scope:  Orion MAK 500
Kodak MAX 800
Focal Ratio: f5.5
Exposure:  12 min
Scope:  Orion MAK 500
MX-5C CCD Camera
Focal Ratio: f5.5
Exposure:  2 min
This image is my attempt to answer the question:  "What do things look like through a telescope"  I have taken the image of M-57 from above and adjusted it so that it approximates the visual appearance of M-57 through my 8" LX 200 using a 26 mm Plossel eyepiece.  Your impression may be different than mine if your skies are darker or if your eyes are better.  But with my magnitude 3.5 to 4 skies and nearly 60 year old eyes, this is just about what M-57 looks like to me.  Now you know why I almost always use the CCD.
Scope:   8" LX 200 SCT
MX-5C CCD Camera & STAR 2000 Auto Tracker
Focal Ratio: f3.3
Exposure:  A 10 min and 20 minute exposure added in Photoshop using a Gaussian Blur mask..
Scope:   8" LX 200 SCT
MX-5C CCD Camera & STAR 2000 Auto Tracker
Focal Ratio: f4.8
Exposure:  10 min
Scope:   8" LX 200 SCT
MX-5C CCD Camera & STAR 2000 Autotracker
Focal Ratio: f6.6
Exposure:  Combined 50 min w/ STAR 2000
Scope:   8" LX 200 SCT
MX-5C CCD Camera
Focal Ratio: f10
Exposure:  Combined 15 min using MX-5C Track & Accumulate software

Click Here for a larger image

Scope:   8" LX 200 SCT
MX-5C CCD Camera & STAR 2000 Auto Tracker
Focal Ratio: f10
Three 20 min using STAR 2000 Auto Tracker combined in MaxIm DL
Scope:   8" LX 200 SCT
MX-5C CCD Camera & STAR 2000 Auto Tracker
Focal Ratio: f20
Five 10 min using STAR 2000 Auto Tracker combined in Astro Art
