Jupiter is
a terrific subject for amateur imaging. The four satellites are always
in motion, and often put on quite a show. You can see the moons cast
a shadow on the face of Jupiter, disappear and reappear as they move in
front of and behind the planet or in and out of Jupiter's shadow.
Occasionally, two or more of the moons will cast a shadow at the same time.
I've included a page that lists when these "dual" shadow events occur.
Click here to see it.
Jupiter itself also put on a show. The cloud bands are constantly changing. You can see these changes with a scope as small as an 8" if you have good seeing. The Great Red Spot (GRS) will move completely across the face of the planet in about 2 hours. You can easily see the GRS in an 8" scope and can often see it in a 6" scope. I've not seen it in a scope smaller that 6", but it may be possible to if seeing is excellent, and the GRS is nice and dark. |
|
Scope:
6" f8 Netwonian Reflector
|
H&W Control Film-ISO 100 | |
This was my first "successful" image of Jupiter. It was taken in 1985 with my Nikon SLR camera and eyepiece projection. This was the best of about 20 images. It shows the difficulty of focusing a film camera at the telescope. | Focal Ratio: f20 through eyepiece projection |
Exposure: ?? | |
This image approximates what Jupiter will look like through an 8-10 scope at about 100 power, except the moons may appear slightly brighter. |
Scope: 8" LX 200 SCT |
MX-5C CCD Camera | |
Focal Ratio: f10 | |
Exposure: 0.005 sec | |
|
Scope:
8" LX 200 SCT
|
MX-5C CCD Camera | |
A typical image with today's technology (Computer controlled telescope, CCD camera, and JMI NGF-S Motofocus.) The GRS is just emerging on the left side of the planet and a shadow of the moon Io is just to the right of center. | Focal Ratio: f20 |
Exposure: 0.25 sec | |
|
Scope:
8" LX 200 SCT
|
MX-5C CCD Camera | |
Jupiter & Io on 25 Sep 99. Click here for a larger image. | Focal Ratio: f20 |
Exposure: 0.25 sec | |
Scope:
8" LX 200 SCT
|
|
MX-5C CCD Camera | |
Jupiter & Three Moons 22 Aug 99. Click here for a larger image. | Focal Ratio: f20 |
Exposure: 0.25 sec | |
Scope:
8" LX 200 SCT
|
|
MX-5C CCD Camera | |
Focal Ratio: f20 | |
These two images show the motion of the GRS and Io during one hour. Click here for a larger image. | |
Exposure:
0.25 sec
|
|
|
